| Quantity: | |
|---|---|
Specification | Max. Output (t/h) | Max. Magnetic Strength (GS) | Input Voltage (V) | Overall Power (kw) | Air Pressure (MPa) | Weight (t) | Dimension (mm) | ||
L | W | H | |||||||
HPCCY5S-2 | 3 | 15000 | 380/415 | 1.1 | 0.6-0.8 | 1.65 | 1550 | 1950 | 1900 |
HPCCY8S-2 | 18000 | 1.8 | 1750 | 2100 | 2000 | ||||
Description
（1）It is used in the industries including ceramics, mines, chemical industry and foods etc. for removing theiron impurities in slurry materials.
（2）The unique magnetic circuit design realizes mutual connection of magnetic force lines among magnetic fields and really form magnetic gather closure magnetic loop.
（3）Magnetic material haven't connected with slurry, no temperature rising, no oxidized easily, with simple structure, low malfunction rate, high reliability and long lifespan.
（4）The unique cleaning system design ensures that the working mediums are cleaned thoroughly each time.
（5）The working cavities run stably and evenly to improve the machine's service life.
（6）It occupies a small area, and it is characterized by high efficiency, energy saving, convenient operation and simple maintenance.
（7）It can be made according to user's needs.
