| Quantity: | |
|---|---|
Specification | Max. Output (t/h) | Max. Magnetic Strength (GS) | Input Voltage (V) | Overall Power (kw) | Air Pressure (MPa) | Weight (t) | Dimension (mm) | ||
L | W | H | |||||||
HPCBC-9 | 15～70 | 11000 | 380/415 | 4 | 0.6-0.8 | 2.15 | 3380 | 2000 | 2700 |
HPCBC-11 | 2.35 | 3760 | |||||||
HPCBC-13 | 2.55 | 4140 | |||||||
HPCBC-15 | 2.8 | 4520 | |||||||
HPCBC-17 | 3.0 | 4900 | |||||||
HPCBC-19 | 5 | 3.2 | 5280 | ||||||
HPCBC-21 | 3.4 | 5660 | |||||||
Description
（1）It is used in the industries including ceramics, mineral processing, chemicals industry and foods etc. for removing theiron impurities in slurry materials.
（2）It is made from high performance magnetic materials which are guaranteed demagnetization ≤5% in 3years under the normal using temperature (<80℃).
（3）The magnet bars sway in the groove, so there is no dead corners and gaps when iron removing. It can effectively remove theiron impurities in the slurry which flow through the groove,the slurry in groove doesn't deposit when running.
（4）Theiron scraping unit is designed as two-sided scraping rings which can remove iron completely to prolong the lifespan of scraping rings.
（5）It is configured with automatic slurry return system, so the system will open the slurry return valve automatically to empty the remaining slurry in the groove to prevent from slurry deposit to damage the machine after machine stopping.
（6）It has advantages in steady performance, high efficiency, energy saving, convenient operation and easy maintenance. Iron removing and cleaning cycle are adjustable.
（7）It can be made according to user's needs.
Specification | Max. Output (t/h) | Max. Magnetic Strength (GS) | Input Voltage (V) | Overall Power (kw) | Air Pressure (MPa) | Weight (t) | Dimension (mm) | ||
L | W | H | |||||||
HPCBC-9 | 15～70 | 11000 | 380/415 | 4 | 0.6-0.8 | 2.15 | 3380 | 2000 | 2700 |
HPCBC-11 | 2.35 | 3760 | |||||||
HPCBC-13 | 2.55 | 4140 | |||||||
HPCBC-15 | 2.8 | 4520 | |||||||
HPCBC-17 | 3.0 | 4900 | |||||||
HPCBC-19 | 5 | 3.2 | 5280 | ||||||
HPCBC-21 | 3.4 | 5660 | |||||||
Description
（1）It is used in the industries including ceramics, mineral processing, chemicals industry and foods etc. for removing theiron impurities in slurry materials.
（2）It is made from high performance magnetic materials which are guaranteed demagnetization ≤5% in 3years under the normal using temperature (<80℃).
（3）The magnet bars sway in the groove, so there is no dead corners and gaps when iron removing. It can effectively remove theiron impurities in the slurry which flow through the groove,the slurry in groove doesn't deposit when running.
（4）Theiron scraping unit is designed as two-sided scraping rings which can remove iron completely to prolong the lifespan of scraping rings.
（5）It is configured with automatic slurry return system, so the system will open the slurry return valve automatically to empty the remaining slurry in the groove to prevent from slurry deposit to damage the machine after machine stopping.
（6）It has advantages in steady performance, high efficiency, energy saving, convenient operation and easy maintenance. Iron removing and cleaning cycle are adjustable.
（7）It can be made according to user's needs.
