| Quantity: | |
|---|---|
| Equipment model | Yield (t/h) | Peak magnetic field (GS) | Input voltage (V) | Power of the machine (kw) | Air source pressure (MPa) | Machine weight (t) | Dimension (㎜) | ||
| long | wide | high | |||||||
| HPXZJ3S-3T | 30 | 10000 | 380/415 | 1.65 | 0.4~0.8 | 1.2 | 2700 | 1850 | 2100 |
| HPXZJ3S-4T | 30 | 10000 | 380/415 | 2.2 | 0.4~0.8 | 1.6 | 3600 | 1850 | 2100 |
| HPXZJ3S-5T | 30 | 10000 | 380/415 | 2.75 | 0.4~0.8 | 2.0 | 4500 | 1850 | 2100 |
Device description
(1) Applicable to ceramics, metallurgy, mining, chemical, food and other industries to remove all kinds of slurry material strong magnetic iron impurities;
(2) The use of high performance magnetic materials, at room temperature use guarantee 3 years of demagnetization ≤5%;
(3) Adopt the integrated layout iron removal production process, the magnetic bar group rotates in the slurry groove, so there is no dead Angle and gap, can more effectively remove strong magnetic iron impurities flowing through the slurry groove material, and the material in the slurry groove will not precipitate during operation;
(4) The scraper device adopts double-sided scraper ring, which can remove iron thoroughly and prolong the service life of the scraper ring;
(5) The equipment is equipped with automatic cleaning system, the minimum water consumption, no special pump, the use of workshop water supply system can be.
(6) The machine has the advantages of stable performance, high efficiency and energy saving, simple maintenance, etc. Iron removal and cleaning cycle time can be adjusted.
(7) Can be customized according to customer requirements.
